Ball Automatic Stripping Machine

Ball Automatic Stripping Machine

  • Simple operation, convenient and quick debugging, easy for beginners to understand and operate.
  • The interface combines animation and action, making it more intuitive. The hydraulic mechanism becomes more visible once activated, and the oil tank pressure is designed with user-friendliness in mind.
  • The tool cuts vertically downwards on the blank, and the chip removal is excellent without sticking to the knife. It is easy to clean up the accumulated chips on the work surface

Description

● Can produceallkinds of ballvalves such as copper balls,sand ball,pig iron blls,plastic balls,stainless stee balls.etc
● Processing pipe diameter range from 20mm to 80mm.
● Production rate:an average of 12 seconds/month,can produce about 2,500 products a day.
● It adopts new process manufacturing,unique design scheme,quicker and more convenient chip removal system,the structure adopts HT300 integralcasting and threetimes aging treatment according to the process to ensure constant shape and precision.Al the power nead noles and rererencesurtaces are installed,and the machining center is used once.Processing completed.
● The biggest advantage of the machine:the product can be peeled off into a mirror with a polishing effect.

Technical Parameters

ItemATK40ATK80ATK130
Spindle speed100-4000r/min100-4000r/min100-2000r/min
Motor power3kW3kW4kW
Weight≈1.3t≈1.3t≈2.1t
Processing materialStainles steel materialStainles steel materialStainless steel material
Processing capacity3-5pcs per minute3-5pcs per minute2-4pcs per minute
Max.bar diameterφ40mmφ80mmφ160mm
Working power supply380V380V380V
PrecisionTrue roundness can reach 0.005mm-0.01mm
Transformer2.5kW
Spindle a synchronous motor4kW Spindle Motor
Wire gaugeHIWIN25

Applicable Scope
